PE film rotogravure printing machine is suitable for gravure multi-color printing of various plastic film, paper and other roll materials. Computer automatic color registration, shaft-less mounting plate, pneumatic scraper, frequency conversion speed regulation, stable tension, accurate registration, high work efficiency, reasonable design, convenient and reliable use.
1. Rewinding double inflatable shafts, non-stop material change.
2. Automatic constant tension for unwinding and unwinding.
3.equipped with air cooling device.
4. Water cooling roller device can be added.
5. Swing roller type double cylinder imprinting.
6. Shaftless air top mounting plate.
7. The drying device is a double-layer circulating hot air box.
8. Centralized exhaust gas device.
9. Computer color register system (brand optional).
10. A still image system can be added (brand optional).
11. PE film rotogravure printing machine can be equipped with positive and negative double-sided printing device.
12. Double-torque motor for rewinding.
| Applicable material | Plastic film,Paper |
| Max.Mechanical speed | 300m/min |
| Web material width | 850,1050,1250,1450,1650mm |
| Registration precision | ≤±0.10mm |
| Max.Unwind & rewind Dia. | Ф800,Ф1000mm |
| Printing cylinder Dia. | Ф120mm-Ф300mm |
| Dry method | Electricity,Steam,Thermal oil or Gas |
Lida Printing & Packaging Machinery is specialized in R&D and production of printing equipment manufacturers and suppliers. The series include: rotogravure printing machine, dry lamination machine, high-speed coating machine, solvent-less lamination machine, inspection rewinder machine etc. All procedures from choosing suppliers, inspection of part processing, supervision of assembly, install & debug of complete set of machine have formed a complete system and flow so that the quality of our products are under control.
